Wastegates 45mm

$399.00

SKU: 6647 Category: Brand:

Description

We are now using Turbosmart.

The new Ultra-Gate38 is a 38mm external wastegate for street and racing applications. Designed with minimum size and maximum flow in mind, the new Ultra-Gate38 is smaller and lighter than the previous model and features Turbosmart’s unique locking collar design for quicker spring changes and a one piece, stainless steel valve.

APPLICATION:
Suitable for all turbocharged vehicles with an external wastegate turbo system. Street and racing applications. Flanges suit 1.50” outside diameter pipe.

SUPPLIED WITH:
Supplied with valve seat, gaskets, all the necessary nuts and bolts, vacuum fittings, 2 x 1/16 NPT Blanks, Collar removal tool. Kit Builder Packs available to customer specifications.

https://youtu.be/MxiB9Rv8LMM
Turbosmart’s 40mm external wastegate was designed to fit into tight engine bays while still offering superior flow and heat handling capabilities. The revolutionary new actuator housing is 25% smaller than our current range and allows for easy spring changes and gives the ability to index the cap orientation in 12 different positions.Supplied With:Inlet and Outlet Stainless Weld Flanges, Inlet and Outlet V-Band Clamps, 1/16 NPT Hose Barbs (5mm), 1/16 NPT Port Blanking Plugs, Locking Collar Tool, Valve Seat, Brown/Purple 7psi Middle Spring (installed).

https://youtu.be/4jyV8Yf3lqY
WG45 2011 Hypergate 45 7psi and WG45 2011 Hypergate 45 14psi. The Turbosmart Hyper-Gate45 is a 45mm external wastegate designed with minimum size and maximum flow in mind. Smaller and lighter than the previous model, the new Hyper-Gate45 features a unique locking collar design for reduced size and quicker spring changes. (Options from 3psi to 26psi available). Features Solid 1 Piece coated Stainless Steel Valve and silicon nomex diaphragm proven for performance and reliability.

WG45 2011 Hypergate 45 35psi. The highest pressure external wastegate of its kind in the world. The Hyper-Gate45HP retains the compactness and lightness synonymous with Turbosmart wastegates with the added bonus of being capable of handling high boost pressures. Only 28mm taller than the standard Hyper-Gate45 these wastegates are ideal for all high boost applications (options from 10psi to 40psi base pressure). Feauturing Solid one-piece coated Stainless Steel Valve and silicon nomex diaphragm proven for performance and reliability.

Additional information

Weight 3.5 lbs
Dimensions 6.75 × 5.5 × 5.5 in
